Transform

Position, rotation and scale of an object.

Type	Name	Interface Description
Variables	localEulerAngles: Vector3f	• Function: Gets the Transform's local euler angles in degrees. Returns The local Euler angles of the Transform.
Variables	localMatrix: Matrix4x4f	• Function: Gets the local transformation matrix of the Transform. Returns The local matrix representing the object's position, rotation, and scale relative to its parent.
Variables	localPosition: Vector3f	• Function: Get the Transform's position relative to its parent. Returns The local position of the Transform.
Variables	localRotation: Quaternionf	• Function: Gets the Transform's rotation relative to its parent. Returns The local rotation as a Quaternionf.
Variables	localScale: Vector3f	• Function: Gets the Transform's scale relative to its parent. Returns The local scale of the Transform.
Functions	constructor()
Functions	getWorldEulerAngles(): Vector3f	• Function: Returns the Transform's Euler angles relative to the world. <br/>Obtaining the rotation in world space may trigger a matrix transformation operation. Returns The world space Euler angles.
Functions	getWorldMatrix(): Matrix4x4f	• Function: Get the world transformation matrix of this object. <br/>Retrieving the world matrix may involve a matrix transformation operation. Returns The world matrix representing the object's position, rotation, and scale in world space.
Functions	getWorldPosition(): Vector3f	• Function: Returns the Transform's position relative to the world. <br/>Obtaining the position in world space may trigger a matrix transformation operation. Returns The position of the Transform in world space.
Functions	getWorldRotation(): Quaternionf	• Function: Returns the Transform's rotation relative to the world. <br/>Obtaining the rotation in world space may trigger a matrix transformation operation. Returns The rotation of the transform in world space.
Functions	getWorldScale(): Vector3f	• Function: Returns the Transform's scale relative to the world. <br/>Obtaining the scale in world space may trigger a matrix transformation operation. Returns The scale of the transform in world space.
Functions	setWorldEulerAngles(euler: Vector3f): void	• Function: Sets the Transform's Euler angles relative to the world. <br/> Setting the world space rotation may trigger a matrix transformation operation. Parameters • euler: - The world space Euler angles.
Functions	setWorldMatrix(matrix: Matrix4x4f): void	• Function: Sets the world transformation matrix for the object. Parameters • matrix: - The 4x4 matrix representing the new world transformation.
Functions	setWorldPosition(worldPosition: Vector3f): void	• Function: Sets the Transform's position in world space. <br/> Modifying the world position may result in a matrix transformation operation. Parameters • worldPosition: - The desired world space position as a Vector3f.
Functions	setWorldRotation(worldRotation: Quaternionf): void	• Function: Sets the Transform's rotation relative to the world. <br/> Setting the world space rotation may trigger a matrix transformation operation. Parameters • worldRotation: - The world space rotation as a Quaternionf.
Functions	setWorldScale(worldScale: Vector3f): void	• Function: Sets the Transform's scale relative to the world. <br/>This may produce lossy results when parent objects are rotated, so use setLocalScale() instead if possible. Parameters • worldScale: - the world space Scale as a Vector3f

Examples

constructor()

let obj = new APJS.Transform();

Use Case

Example 1 — Pin one or more 2D screen-space overlays (Profile Photo, Screen Image, 2D Text) to follow 3D world targets every frame.

// Pin one or more 2D screen-space overlays (Profile Photo / Screen Image / 2D Text)
// to follow 3D world targets every frame using the 3D camera's projection.
//
// Each pair is configured by index in the parallel arrays target3DTransform[i] /
// overlay2DTransform[i]. Pair count = min of the two array lengths.
//
// Engine note (verified 2026-04-29 in scratch): when an array of SceneObject refs is
// wired through DSL set_component, the engine coerces each entry to that object's
// first component (Transform / ScreenTransform). This script accepts those component
// arrays directly, so you wire targets with their Transform components and overlays
// with their ScreenTransform components for a 1:1 mapping. We retrieve the owning
// SceneObject via Transform.getSceneObject() to honor enabled state.
//
// Scene authoring (DSL):
// - Camera (3D, perspective): the world camera that frames the gameplay scene.
// - 2D Camera (orthographic): the camera under which UI elements live.
// - Targets: any 3D objects with a Transform (typically tower-block Cubes with
//   RigidBody + BoxCollider, but the script doesn't require physics).
// - Overlays: 2D UI elements parented to 2D Camera (Profile Photo, Screen Image,
//   2D Text). The script writes their world position via Transform.setWorldPosition.
//
// DSL wiring of array properties (use explicit type=Transform / ScreenTransform —
// SceneObject refs auto-coerce, but being explicit avoids ambiguity):
//   set_component on the WorldToScreenFollower component:
//     properties: {
//       camera3DObject: { guid: '<3D-cam-SceneObject-guid>' },
//       camera2DObject: { guid: '<2D-cam-SceneObject-guid>' },
//       target3DTransform: [
//         { guid: '<block0-Transform-guid>', type: 'Transform' },
//         { guid: '<block1-Transform-guid>', type: 'Transform' },
//         ...
//       ],
//       overlay2DTransform: [
//         { guid: '<photo0-ScreenTransform-guid>', type: 'ScreenTransform' },
//         { guid: '<photo1-ScreenTransform-guid>', type: 'ScreenTransform' },
//         ...
//       ]
//     }
//
// Verified 2026-04-29 (experiment G11) on a 3-cube static stack at world y =
// 0.80 / 1.60 / 2.40 → screen y = 568 / 662 / 760 (px, origin bottom-left); each
// 0.8u world-y delta maps to ~94 screen-px delta as expected from the 3D camera
// at (0,3,5) with -10° pitch and 60° FOV. Drop test: tower compressed to y =
// 0.60 / 1.39 / 2.19 → screen y = 544 / 637 / 734, all 3 photos lock-step.
@component()
export class WorldToScreenFollower extends APJS.BasicScriptComponent {
  @serializeProperty
  private camera3DObject!: APJS.SceneObject;

  @serializeProperty
  private camera2DObject!: APJS.SceneObject;

  @serializeProperty
  private target3DTransform: APJS.Transform[] = [];

  @serializeProperty
  private overlay2DTransform: APJS.Transform[] = [];

  @serializeProperty
  private logEvery: number = 0;

  // Hide the 2D overlay when its target SceneObject is disabled (e.g. knocked-down
  // block destroyed). Set to false to keep the overlay rendered at the last
  // tracked position regardless of target state.
  @serializeProperty
  private hideWhenTargetDisabled: boolean = true;

  private camera3D!: APJS.Camera;
  private camera2D!: APJS.Camera;
  private inited: boolean = false;
  private pairCount: number = 0;
  private frame: number = 0;

  private initOnce(): void {
    if (!this.camera3DObject || !this.camera2DObject) {
      return;
    }
    this.camera3D = this.camera3DObject.getComponent('Camera') as APJS.Camera;
    this.camera2D = this.camera2DObject.getComponent('Camera') as APJS.Camera;
    if (!this.camera3D || !this.camera2D) {
      return;
    }
    this.pairCount = Math.min(this.target3DTransform.length, this.overlay2DTransform.length);
    this.inited = true;
    console.log('[W2S] init pairs=' + this.pairCount + ' cam3D=' + this.camera3DObject.name + ' cam2D=' + this.camera2DObject.name);
  }

  onUpdate(_dt: number): void {
    if (!this.inited) {
      this.initOnce();
      return;
    }
    this.frame++;
    const log = this.logEvery > 0 && this.frame % this.logEvery === 0;
    for (let i = 0; i < this.pairCount; i++) {
      const tT = this.target3DTransform[i];
      const oT = this.overlay2DTransform[i];
      if (!tT || !oT) {
        continue;
      }
      const targetObj = tT.getSceneObject();
      const overlayObj = oT.getSceneObject();
      if (!targetObj || !overlayObj) {
        continue;
      }
      const targetEnabled = targetObj.enabled;
      if (this.hideWhenTargetDisabled && overlayObj.enabled !== targetEnabled) {
        overlayObj.enabled = targetEnabled;
      }
      if (!targetEnabled) {
        continue;
      }
      const wp = tT.getWorldPosition();
      const screen3 = this.camera3D.worldToScreenPoint(wp);
      const wp2 = this.camera2D.screenToWorldPoint(
        new APJS.Vector3f(screen3.x, screen3.y, 40)
      );
      oT.setWorldPosition(wp2);
      if (log) {
        console.log('[W2S] f=' + this.frame + ' i=' + i + ' ' + targetObj.name + '->' + overlayObj.name + ' world=(' + wp.x.toFixed(2) + ',' + wp.y.toFixed(2) + ',' + wp.z.toFixed(2) + ') screen=(' + screen3.x.toFixed(0) + ',' + screen3.y.toFixed(0) + ')');
      }
    }
  }
}

Example 2 — Camera-follow variant of a 3D lane-switch runner — the player traverses -Z, a chase camera trails on the +Z side and lerps toward player + cameraOffset each f…

@component()
export class CameraFollowRunner3D extends APJS.BasicScriptComponent {
  @serializeProperty player: APJS.SceneObject;
  @serializeProperty camera: APJS.SceneObject;
  @serializeProperty trackTiles: APJS.SceneObject[];

  @serializeProperty speed: number = 8;             // forward units per second toward -Z
  @serializeProperty smoothness: number = 6;        // larger = camera catches up faster
  @serializeProperty tileLength: number = 14;       // world Z length of one track tile
  @serializeProperty cameraOffsetY: number = 8;     // camera height above player
  @serializeProperty cameraOffsetZ: number = 10;    // camera distance behind player on the +Z side

  private playerTr: APJS.Transform;
  private cameraTr: APJS.Transform;
  private tileTrs: APJS.Transform[] = [];
  private initialized = false;

  onUpdate(dt: number): void {
    if (!this.initialized) {
      if (!this.player || !this.camera || !this.trackTiles || this.trackTiles.length < 2) {
        return; // wiring not ready yet — skip the frame
      }
      this.playerTr = this.player.getComponent("Transform") as APJS.Transform;
      this.cameraTr = this.camera.getComponent("Transform") as APJS.Transform;
      this.tileTrs = [];
      for (let i = 0; i < this.trackTiles.length; i++) {
        const t = this.trackTiles[i];
        if (t) this.tileTrs.push(t.getComponent("Transform") as APJS.Transform);
      }
      this.initialized = true;
    }

    // 1. Advance player forward along -Z. Lane (x) and jump (y) are owned by
    //    the runner's own input handler; this script only owns the forward axis.
    const p = this.playerTr.localPosition;
    const newPlayerZ = p.z - this.speed * dt;
    this.playerTr.localPosition = new APJS.Vector3f(p.x, p.y, newPlayerZ);

    // 2. Lerp camera toward (player + offset). The camera trails on +Z, matching
    //    the default template Camera at z=30 behind the Player at z=20.
    const c = this.cameraTr.localPosition;
    const targetX = p.x;
    const targetY = this.cameraOffsetY;
    const targetZ = newPlayerZ + this.cameraOffsetZ;
    const k = Math.min(1, dt * this.smoothness);
    this.cameraTr.localPosition = new APJS.Vector3f(
      c.x + (targetX - c.x) * k,
      c.y + (targetY - c.y) * k,
      c.z + (targetZ - c.z) * k
    );

    // 3. Recycle track tiles. The runner moves toward lower Z, so the front-most
    //    tile has the smallest z and the back-most tile has the largest z. If the
    //    back-most tile is more than 1 tileLength behind the player, teleport it
    //    to frontmost.z - tileLength.
    if (this.tileTrs.length >= 2) {
      let backIdx = 0;
      let backZ = this.tileTrs[0].localPosition.z;
      let frontZ = backZ;
      for (let i = 1; i < this.tileTrs.length; i++) {
        const z = this.tileTrs[i].localPosition.z;
        if (z > backZ) { backZ = z; backIdx = i; }
        if (z < frontZ) { frontZ = z; }
      }
      if (backZ - newPlayerZ > this.tileLength) {
        const back = this.tileTrs[backIdx].localPosition;
        this.tileTrs[backIdx].localPosition = new APJS.Vector3f(back.x, back.y, frontZ - this.tileLength);
      }
    }
  }
}
